特點(diǎn)：
●體積小（35x9mm）
●聲壓高（12VDC時(shí)≥85dB）
●消耗電流（≤40mA，12VDC）
●安裝簡便（臥式會腳插入焊接）
電性能參數(shù)
Model No | BCE-D31220-12V |
Rated Voltage | 12V |
Min Sound Pressure Level | 85dB at 10 cm |
Operating Voltage | 7-15V |
Max Current Consumption | 40mA |
Resonant Frequency | 2000±500HZ |
Housing Material | PBT |
Operating Temperature | -20℃~+70℃ |
Storage Temperature | -30℃~+80℃ |
Weight | 11g |
